Gigabyte GA-P35-DS3R ATX LGA775 Conroe P35 DDR2 1PCI-E16 3PCI-E1 SATA RAID Sound GBLAN Motherboard

Other products from GIGABYTE | (3 customer reviews)

Photos may not resemble actual product and are purely for illustration purposes
View more product photos
Availability:

Not Available

Details:

Shipping Weight: 5 lbs

SKU #: (11830BD0443)

Mft. Part #: GA-P35-DS3R

Our Price:

$132.95

Canadian Funds

Add to wish List

Tell a friend

More from GIGABYTE

More like this

Print page

Specifications | 3 Customer Reviews | Warranty Information | Sales Terms | Discuss in Forum
HardwareWiki.org Info
Specifications























































































  Introduction
The GA-P35-DS3R is GIGABYTE high performance platform based on the killer combination of the new Intel P35 chipset plus support for the latest multi-core processors up to FSB 1333MHz, including the upcoming 45nm platform. The GA-P35-DS3R is also part of the GIGABYTE Ultra Durable 2 Series of motherboards, featuring top quality electronic components which provide optimized power savings, ultra cooling and extended system durability.
  Ultra Durable 2 -Designed with Top Quality Highly Efficient Components

Ultra Durable 2

Ultra Cooling - Low RDS(on) MOSFET Design
Low RDS(on) MOSFETs specially designed to produce lower switching resistance for faster electric current charging and discharging.
Ultra Cooling

Low Power Loss - Ferrite Core Choke Design
Ferrite core chokes comprised of a compound of iron oxide and other metal elements whose properties hold energy much longer than common iron core at high frequency.
Low Power Loss






Longer Life - All-Solid Capacitor Design
Solid capacitors contain a solid organic polymer, while electrolytic capacitors use a common liquid electrolyte, hence, the terms solid capacitor versus electrolytic capacitors.
Longer Life
 Intel® Core™ 2 multi-core and upcoming 45nm processors
GA-P35-DS3R supports Intel latest high performance CPU delivers the most energy-efficient performance available today. Based on Intel's Micro Architecture, the Intel multi-core processors with 4 cores and two shared L2 caches provide the best capability-per-watt solutions and are an ideal choice for multi-media enthusiasts and intensive multi-tasking environments. This cutting-edge processor offers significant performance boosts and provides an overall more energy efficient platform.
 Intel® P35 Express Chipset
The Intel® P35 Express Chipsets support the latest multi-core processors up to FSB 1333MHz, including the upcoming 45nm platform, with its record breaking performance and greater energy efficiency. Intel® P35 chipset, with optimized system memory capabilities, chipset over-speed protection removed for maximum overclocking and Intel® Turbo Memory technology, providing faster boot and application load times and additional power savings. Intel® P35 chipset also offer options for both DDR2 and DDR3 memory support, providing scalable options for users wanting to take advantage of higher memory performance with less power consumption to run next generation applications such as high-definition video and 3D visualization.
 Windows Vista Premium Logo Certified
Windows Vista Premium promises to deliver a streamlined computing experience designed to fundamentally change how users view, find and organize their digital information. With P35/G33/P965/G965/946/945 solutions all enabling support for Vista Premium, GIGABYTE offers a fresh and unique desktop experience that will be more informative, intuitive and completely new...more
 Dual Channel DDR2 1066
Experience the advanced technology of DDR2 1066 memory, featuring faster speeds and higher data bandwidth, which delivers superior performance for the most demanding applications.
 SATA 3Gb/s storage interface
The SATA specification doubles bus bandwidth from 1.5Gb/s to 3Gb/s. Native Command Queuing is a new specification that enables out-of-order execution of commands for efficient retrieval of data. Hot Plug support allows users to insert and remove hard disk drives without shutting off power to the system.
  ALC889A Enables a Superior Audio Experience

Excellent Audio Performance
High-performance DAC (Digital-Analog Converter) with 106 dB Signal-to-Noise ratio playback quality, designed especially for Windows Vista Premium PCs.



Blu-ray/HD DVD Full Rate Audio Support
The ALC889A enables high quality Full Rate Lossless Audio for content protected media and support for both Blu-ray and HD DVD formats for an exhilarating home theater entertainment experience.


7.1+2 Channel High Definition Output
The ALC889A provides support for 7.1 sound playback, plus 2 channels of independent stereo output (multiple streaming) through the front panel stereo outputs.
 Intel® Matrix Storage Technology
Intel® Matrix Storage Technology, can deliver up to 80% faster storage performance with PCs equipped with two hard drives using RAID 0 data striping. Using RAID 1 data mirroring can protect against a hard drive failure by mirroring all data among two hard drives. In addition RAID 5 offers the fault-tolerant capability to automatically back up your most important files, while also providing faster disk access and adding storage capacity.



 Gigabit LAN connectivity
The Gigabit network interface delivers a high speed LAN connection with data transfer rate up to 1000Mb/s, providing new generation connectivity for the broadband era. Gigabit LAN is ideally for seamless internet connection such as streaming audio and video contents
 RoHS compliant
As a member of the global community to look after the environment, Gigabyte complies with the European Union's Restriction of use of certain Hazardous Substances (RoHS) directive which limits the use of lead, mercury, cadmium and other hazardous substances in electronic products. From components and material selection to production processes, make up of accessories, packaging/color boxes etc; GIGABYTE has carefully examined and designed this product to be 100% RoHS compliant. GIGABYTE will continue to develop RoHS compliant PC components and commit valuable resources to promoting and advancing RoHS directive goals and objectives.
 Speed
The Speed compliant motherboards of GIGABYTE S-series provide intelligent over-clocking and over-voltage software settings through both hardware and software design...more
 Smart
The Smart featured motherboards of GIGABYTE S-series provide GIGABYTE proprietary innovative software such as Download Center, @BIOS, Q-Flash, Xpress Install, Boot menu, and Smart Fan. BIOS and driver management now becomes much easier and user friendly through GIGABYTE Smart features!...more
 Safe
Safe is the key feature of GIGABYTE S-series motherboards with the following elements: Excellent hardware design reinforced BIOS protection through GIGABYTE Virtual Dual BIOS Technology and GIGABYTE BIOS Setting Recovery Technology. Unique system software such as Xpress Recovery 2, PC Health Monitor, HDD S.M.A.R.T., and C.O.M. further strengthen the stability and reliability of your PC!...more


Additional Information

  • ROHS Compliant
  • Native DDR2-1066MHz support available

    • Chipset:

  • Northbridge: Intel P35 Express Chipset
  • Southbridge: Intel ICH9R

    • BIOS Features:

  • Supports Virtual DualBIOS
  • 1 x 8 Mbit flash
  • Use of licensed AWARD BIOS
  • PnP 1.0a, DMI 2.0, SM BIOS 2.3, ACPI 1.0b

    • Unique Features:

  • Ultra Durable 2 Motherboard
  • All Japanese manufactured solid
  • Over-clocking Enhanced
  • Support for @BIOS
  • Support for Download Center
  • Support for Q-Flash
  • Support for EasyTune
  • Support for Xpress Install
  • Support for Xpress Recovery2
  • Support for Virtual Dual BIOS

    • Hardware Monitoring:

  • System voltage detection
  • CPU/System temperature detection
  • CPU/System/Power fan speed detection
  • CPU overheating warning
  • CPU/System/Power fan fail warning
  • CPU fan speed control

    • Supported Operating Systems:

  • Microsoft Windows Vista
  • Microsoft Windows XP
  • Microsoft Windows 2000


    		•
    Audio Channels    7.1
    Back Panel Interfaces    2 x mini-DIN
    4 x Type A USB 2.0 USB
    1 x DB-9 RS-232 Serial
    1 x Toslink S/PDIF Out
    1 x S/PDIF Out
    1 x DB-25 IEEE 1284 Parallel
    1 x RJ-45 Network
    1 x Mini-phone Microphone
    4 x Mini-phone Audio Line Out
    1 x Mini-phone Audio Line In
    Brand Name    GIGA-BYTE
    Chipset Manufacturer    Intel
    Chipset Model    P35 Express
    Dimensions    12" Width x 8.27" Depth
    Expansion Slots    1 x PCI Express x16
    3 x PCI Express x1
    3 x PCI
    Floppy Controller    Yes
    Front Panel Interfaces    1 x HDD LED
    1 x Reset Switch
    1 x On/Off Switch
    1 x Power LED
    1 x Chassis Intrusion Switch
    4 x USB Header
    1 x S/PDIF In
    1 x CD-in/Aux-in Connector
    1 x Audio Header
    Front Side Bus    533 MHz
    800 MHz
    1066 MHz
    1333 MHz
    Gigabit Ethernet    Yes
    IDE Controller    Yes
    IDE Standard    Ultra ATA/133 (ATA-7)
    Manufacturer    GIGA-BYTE TECHNOLOGY CO
    Manufacturer Part Number    GA-P35-DS3R
    Manufacturer Website Address    http://www.giga-byte.com
    Marketing Information

    The GA-P35-DS3R is GIGABYTE high performance platform based on the killer combination of the new Intel P35 chipset plus support for the latest multi-core processors up to FSB 1333MHz, including the upcoming 45nm platform. The GA-P35-DS3R is also part of the GIGABYTE Ultra Durable 2 Series of motherboards, featuring top quality electronic components which provide optimized power savings, ultra cooling and extended system durability.


    Maximum Memory    8 GB
    Memory Standard    DDR2-533/PC2-4200
    DDR2-667/PC2-5300
    DDR2-800/PC2-6400
    Memory Technology    DDR2 SDRAM
    Number of IDE Interfaces    1
    Number of Memory Slots    4
    Number of SATA Interfaces    8
    Processor Socket    Socket T
    Processor Support    Core 2 Extreme
    Core 2 Quad
    Pentium Extreme Edition
    Pentium 4
    Celeron D
    Celeron
    Pentium 4 (Extreme Edition)
    Processor Technology    Hyper-Threading Technology
    Product Model    GA-P35-DS3R
    Product Name    GA-P35-DS3R Desktop Board
    Product Series    Ultra Durable 2
    Product Type    Desktop Board
    SATA Controller    Yes
    SATA Standard    Serial ATA/300
    Sound Controller Manufacturer    Realtek
    Sound Controller Model    ALC889A
    Total Processor Support    1
    1010892081
    Customer Reviews

    Reviewed by TG2010016794 at @ 10:38 AM Feb 17, 2008


    Great board all around, with plenty of fan connectors and expansion capabilities.
    Definately recommended to anyone looking for a quality board. Includes solid caps, so no fear of the old bulging capacitor problems.

    Reviewed by done at @ 06:29 PM Nov 28, 2007

    I like the 8 sata connections which leaves lots of room for things. I have sold three since the beginning of the year and like it a lot. Lots of fan connections and easy to install.

    Reviewed by AH2010005244 at @ 06:34 PM Aug 02, 2007

    Very nice motherboard with excellent features. FSB goes up high - right now I have it at 472x7 on my E6300 @ 3.3G, only my 667 RAM is holding me back. Don't forget to press Ctrl+F1 in the bios to be able to change the memory timings.
